Wildeye Wiring - Netafim IRT
Tools required:
- Wire strippers
- A way to secure two bare wire connections
Installation Materials:
1 x Wildeye Cable (part# WILD-CAB-M12-M-5)
Instructions:
A "Pulse Reed Switch" module must be installed onto the register to get pulse output.
- Connect the wires, black to black and red to white.
- Secure the wires together
| Function | Wildeye Color | Netafim IRT |
| Counter | Black | Black |
| Ground | White | Red |
Wildeye support line: 559-464-8300
